Basic image resizing operations
Resizing operations enable the dynamic generation of image transformations to meet various web delivery use cases. Operations focus on the image size while Filters allow to modify the image itself.

Available operations

Operation
Syntax
Description
width=X
sets the image width to X pixels
height=X
sets the image height to X pixels
org_if_sml=1
prevents resizing if the target size is larger than the origin image
Crop
func=crop
sets crop resize function
gravity=X
defines the part of the image to be retained when cropping X = [north | south][east | west] | auto | X,Y
tl_px=X,Y
sets coordinates of the top left corner of the cropping rectangle
br_px=X,Y
sets coordinates of the bottom right corner of the cropping rectangle
Face crop
func=face
crops the image automatically focusing on the most prominent face
Fit
func=fit
sets fit resize function
Cropfit
func=cropfit
sets crop or fit resize function depending on the origin and the desired dimensions
Bound
func=bound
sets bound resize function
Boundmin
func=boundmin
bounds the image to the larger dimension
Cover
func=cover
sets cover resize function (distorts image proportions)
Flip
flip=[h][v]
mirrors the image horizontally and/or vertically
Rotate
r=X
rotates the image to X degrees (counterclockwise)
Trim
trim=X
trims any solid-color border (if present); X is the aggressiveness of the operation
radius=X
applies rounded corners and optionally fills the empty background with a color
Do not hesitate to contact us if you need any additional operations not listed above

Resize functions

When you specify both width and height, original image proportions can be either ignored or maintained. Also, you may choose to add padding to the image to fill the blank space.
Filerobot supports the following resize function (operation func).

Crop

Keeps image proportions cutting the image to fit the defined width and height; see Crop
This resizing function removes parts of the image and is the default behaviour when both width and height are defined. Read further for other resizing functions.
Preview
Syntax

Fit

Resizes the image keeping proportions and adding padding to satisfy the desired dimensions; see Fit

Cropfit

Performs either Cropor Fit based on image dimensions and transformation parameters; see Cropfit
This resizing function may remove parts of the image
Preview
Syntax
Same parameters, 400x250 origin image: /docs/ny_doc.jpg?func=cropfit&w=500&h=350&bg_colour=auto

Bound

Fits image in a box of defined size without adding padding; see Bound
The boundmin operation is a special case of bound where the smaller dimension is respected instead of the larger one, see boundmin

Cover

Resizes the image to the given width and height ignoring original image proportions, thus distorting the image; see Cover
For troubleshooting purposes, use the ci_info=1 operation to view details about resizing and compression, for example: /docs/hotel.jpg?w=400&ci_info=1
